In march of 2025 we were lucky and fortunate to get our hands on a 2025 ram 2500 with the 8AP transmission, after tons of coding and design work and doing 2 swaps we released a statement about them , we had an open house where we did a full unavailing of the 5th gen 8AP swap , fully functioning.

During that open house we had 4 controllers ready to go . We sold all 4 without an any hesitation. We have Decided to make this project open source for the betterment of the industry. We knew this swap would be bigger then just one company, and it would be very unfair for just one company to monopolize the market for these swaps.

So our goal is to open it up to the public for Development so companies / hobbiest can make their own controller for public and private us. The goal and intent to sharing this , so others can create a controller based off this code and in hopes different variations could be created and improvements could be made by anyone and everyone.

In the mean time ill work on a forum for this topic so everything can be shared by individuals.

If you have any questions , please email us anytime and we will respond when we have time, please subject line 8AP. we will add to this from time to time, so please check our facebook page for any updates.

Thanks, Enjoy

PRECISION DIESEL INJECTION

⚙️ Key Hard Parts / Components

8AP TRANSMISSION W/ TQ CONVERTER – 68719744AA / 68719742AA
TRANSMISSION ADAPTER – 68723536AA / AFTERMARKET (CONTACT US AND WE CAN BUILD YOU ONE)
FLEX PLATE – 68444379AA (10 BOLT CRANK PATTERN ( FOR EARLY 5.9/6.7 CRANK PATTERN PLEASE CONTACT US AND WE CAN BUILD YOU ONE)
BW44-46 TRANSFER CASE – 68546814AA / 68546815AA ( OR CONTACT US FOR A AFTERMARKET INPUT SHAFT TO MODIFY YOUR PRE 2025 BW 44-46 TO FIT 8AP INPUT SHAFT / CURRENTLY WORKING ON A CUSTOM T CASE INPUT FOR THE NP271/NP273 )
GEAR SELECTOR CABLE – 68350303AE & 68596112AB
FRONT AND REAR DRIVESHAFT MODIFICATIONS ARE REQUIRED – IF YOU DONT WISH TO MODIFY YOUR FRONT SHAFT , YOU CAN BUY A OEM ONE

FRONT – 68312648ae

REAR 1 PIECE (SHORT BED) – 68649157AB

REAR 2 PIECE (MEGA AND LONG BED) – 68649050AA / 68649051AA

YOU WILL BE BETTTER OFF SOURCING YOUR OWN HARDWARE
TRANSMISSION MOUNT MODIFICATIONS OR CUSTOM MOUNT MADE. YOU COULD SOURCE A 2025-2026 AND MODIFY TO WORK ON EARLY FRAME WITH MODIFICATIONS.

Inputs

Engine RPM (CAN)
Throttle / Torque Request (CAN)
Vehicle Speed (CAN)
Brake Switch
Trans Temp
Mode Selector (Tow / Street / Sport)

Outputs

Shift Solenoids (A–E)
Pressure Regulator
TCC Control
CAN feedback to ECM (torque reduction request)

#include <stdint.h>
#include <stdbool.h>

/* =============================
   CONSTANTS
============================= */
#define MAX_GEAR 8
#define LINE_PRESSURE_MAX 100
#define LINE_PRESSURE_MIN 30
#define TEMP_LIMIT 120   // Celsius
#define RPM_REDLINE 3200

/* =============================
   ENUMS
============================= */
typedef enum {
    MODE_TOW,
    MODE_STREET,
    MODE_SPORT
} DriveMode;

typedef enum {
    GEAR_P = 0,
    GEAR_R,
    GEAR_N,
    GEAR_1,
    GEAR_2,
    GEAR_3,
    GEAR_4,
    GEAR_5,
    GEAR_6,
    GEAR_7,
    GEAR_8
} Gear;

/* =============================
   STATE STRUCT
============================= */
typedef struct {
    uint16_t rpm;
    uint16_t vehicle_speed;
    uint8_t throttle;
    uint8_t trans_temp;
    bool brake;
    DriveMode mode;
    Gear current_gear;
} TCU_State;

/* =============================
   SHIFT TABLES (MPH)
============================= */
const uint8_t upshift_table[3][8] = {
    /* Tow */
    {0, 12, 22, 32, 42, 52, 62, 72},
    /* Street */
    {0, 15, 28, 40, 55, 68, 80, 92},
    /* Sport */
    {0, 20, 35, 55, 75, 95, 115, 135}
};

const uint8_t downshift_table[3][8] = {
    {0, 10, 18, 26, 36, 46, 56, 66},
    {0, 12, 22, 34, 48, 60, 72, 82},
    {0, 18, 30, 48, 65, 85, 105, 120}
};

/* =============================
   LINE PRESSURE LOGIC
============================= */
uint8_t calculate_line_pressure(TCU_State *s) {
    uint8_t pressure = LINE_PRESSURE_MIN;

    pressure += s->throttle / 2;
    pressure += (s->mode == MODE_SPORT) ? 15 : 0;

    if (s->trans_temp > TEMP_LIMIT)
        pressure += 10;

    if (pressure > LINE_PRESSURE_MAX)
        pressure = LINE_PRESSURE_MAX;

    return pressure;
}

/* =============================
   SHIFT DECISION
============================= */
Gear calculate_gear(TCU_State *s) {
    uint8_t mode = s->mode;

    if (s->current_gear < GEAR_8 &&
        s->vehicle_speed > upshift_table[mode][s->current_gear]) {
        return s->current_gear + 1;
    }

    if (s->current_gear > GEAR_1 &&
        s->vehicle_speed < downshift_table[mode][s->current_gear]) {
        return s->current_gear - 1;
    }

    return s->current_gear;
}

/* =============================
   TORQUE MANAGEMENT
============================= */
void request_torque_reduction(uint8_t percent) {
    // Send CAN message to ECM
    // Example: 0x180, data[0] = percent
}

/* =============================
   APPLY SHIFT
============================= */
void apply_shift(Gear new_gear) {
    request_torque_reduction(30);
    // Solenoid sequencing happens here
}

/* =============================
   MAIN LOOP
============================= */
void tcu_update(TCU_State *s) {
    if (s->rpm > RPM_REDLINE)
        return;

    Gear target_gear = calculate_gear(s);

    if (target_gear != s->current_gear) {
        apply_shift(target_gear);
        s->current_gear = target_gear;
    }

    uint8_t pressure = calculate_line_pressure(s);
    // Output pressure command
}

/* =============================
   ENTRY POINT
============================= */
int main(void) {
    TCU_State tcu = {
        .rpm = 0,
        .vehicle_speed = 0,
        .throttle = 0,
        .trans_temp = 40,
        .brake = false,
        .mode = MODE_STREET,
        .current_gear = GEAR_1
    };

    while (1) {
        // Update CAN inputs here
        tcu_update(&tcu);
    }
}

🧩 What This File Already Does

✅ 8-speed shift logic
✅ Mode-based behavior
✅ Adaptive line pressure
✅ Torque reduction hooks
✅ Over-temp protection
✅ CAN-ready structure

🧠 CONTROL STRATEGY (IMPORTANT)

We’ll run two main calibrations inside one controller:

🟦 TOW MODE (default)

Early lockup
Conservative RPM
Max clutch protection
Thermal priority
Torque-managed shifts

🟥 RACE MODE

Late shifts
Full line pressure
Minimal torque reduction
Faster clutch fill
Lockup under power

Mode selectable via:

Toggle switch
CAN command
Throttle + brake combo (failsafe)

🔧 Core Constants

#define MAX_GEAR 8
#define RPM_REDLINE_TOW   2800
#define RPM_REDLINE_RACE  3600

#define LINE_PRESSURE_MIN 40
#define LINE_PRESSURE_MAX 100

#define TEMP_WARN 110
#define TEMP_LIMP 130

#define TORQUE_REDUCTION_TOW 40
#define TORQUE_REDUCTION_RACE 10

🧩 Enums & State

typedef enum {
    MODE_TOW,
    MODE_RACE
} DriveMode;

typedef enum {
    GEAR_P = 0,
    GEAR_R,
    GEAR_N,
    GEAR_1,
    GEAR_2,
    GEAR_3,
    GEAR_4,
    GEAR_5,
    GEAR_6,
    GEAR_7,
    GEAR_8
} Gear;

typedef struct {
    uint16_t rpm;
    uint16_t vehicle_speed;
    uint8_t throttle;
    uint8_t trans_temp;
    bool brake;
    DriveMode mode;
    Gear gear;
} TCU;

📊 SHIFT TABLES (MPH)

Tow = Load-biased, safe

Race = RPM-biased, aggressive

const uint8_t upshift_tow[8]  = {0, 14, 24, 34, 44, 54, 64, 74};
const uint8_t downshift_tow[8]= {0, 10, 18, 26, 36, 46, 56, 66};

const uint8_t upshift_race[8]  = {0, 28, 48, 68, 88, 108, 128, 148};
const uint8_t downshift_race[8]= {0, 22, 38, 54, 72, 90, 108, 126};

🧮 LINE PRESSURE LOGIC (8AP-SAFE)

uint8_t calc_line_pressure(TCU *t) {
    uint8_t p = LINE_PRESSURE_MIN;

    p += t->throttle / 2;

    if (t->mode == MODE_RACE)
        p += 20;

    if (t->trans_temp > TEMP_WARN)
        p += 10;

    if (p > LINE_PRESSURE_MAX)
        p = LINE_PRESSURE_MAX;

    return p;
}

🔄 SHIFT DECISION

Gear calc_target_gear(TCU *t) {
    if (t->gear < GEAR_8) {
        if (t->mode == MODE_TOW &&
            t->vehicle_speed > upshift_tow[t->gear])
            return t->gear + 1;

        if (t->mode == MODE_RACE &&
            t->vehicle_speed > upshift_race[t->gear])
            return t->gear + 1;
    }

    if (t->gear > GEAR_1) {
        if (t->mode == MODE_TOW &&
            t->vehicle_speed < downshift_tow[t->gear])
            return t->gear - 1;

        if (t->mode == MODE_RACE &&
            t->vehicle_speed < downshift_race[t->gear])
            return t->gear - 1;
    }

    return t->gear;
}

🔐 TORQUE MANAGEMENT (CRITICAL)

void torque_request(uint8_t percent) {
    // CAN TX to ECM
    // Example ID: 0x180
    // data[0] = percent
}

void begin_shift(DriveMode mode) {
    if (mode == MODE_TOW)
        torque_request(TORQUE_REDUCTION_TOW);
    else
        torque_request(TORQUE_REDUCTION_RACE);
}

⚙️ APPLY SHIFT (8AP CLUTCH SAFE)

void apply_shift(TCU *t, Gear new_gear) {
    begin_shift(t->mode);

    // --- Clutch swap timing ---
    // Pre-fill next clutch
    // Release current clutch
    // Ramp pressure

    t->gear = new_gear;
}

🔒 TORQUE CONVERTER LOCKUP

bool allow_lockup(TCU *t) {
    if (t->trans_temp > TEMP_WARN)
        return false;

    if (t->mode == MODE_TOW)
        return (t->gear >= GEAR_3 && t->throttle < 60);

    // Race mode
    return (t->gear >= GEAR_2);
}

🚨 PROTECTION / LIMP MODE

void protection(TCU *t) {
    if (t->trans_temp > TEMP_LIMP) {
        t->mode = MODE_TOW;
        t->gear = GEAR_3;  // limp gear
    }
}

🔁 MAIN LOOP

void tcu_loop(TCU *t) {
    protection(t);

    Gear target = calc_target_gear(t);

    if (target != t->gear)
        apply_shift(t, target);

    uint8_t pressure = calc_line_pressure(t);
    // Output pressure command
}

1️⃣ ZF 8AP Clutch & Solenoid Map (FOUNDATION)

Common naming (may vary slightly by valve body):

A = Forward clutch
B = Brake clutch
C = Overdrive clutch
D = Direct clutch
E = Low / Reverse clutch

🧮 Gear Truth Table

Gear	A	B	C	D	E
1	✔	❌	❌	❌	✔
2	✔	✔	❌	❌	❌
3	✔	✔	✔	❌	❌
4	✔	❌	✔	✔	❌
5	✔	❌	❌	✔	✔
6	✔	✔	❌	✔	❌
7	✔	✔	✔	✔	❌
8	✔	❌	✔	✔	✔
R	❌	✔	❌	❌	✔

👉 Only one clutch changes per shift = durability.

⚡ Solenoid Assignments (Typical)

Solenoid	Function
S1	Clutch A
S2	Clutch B
S3	Clutch C
S4	Clutch D
S5	Clutch E
SL	Line Pressure
ST	TCC

2️⃣ Cummins CAN MAP (WHAT YOU READ & WRITE)

📥 Incoming CAN (Read-Only)

Signal	CAN ID	Bytes
RPM	`0x0CFFF048`	2–3
Throttle %	`0x18FF0123`	1
Engine Torque	`0x18FF0201`	2
Coolant Temp	`0x18FEEE00`	1

📤 Outgoing CAN (To ECM)

Command	CAN ID
Torque Reduction	`0x180`
Gear Display	`0x1A0`
Lockup Status	`0x1A1`

ECM torque request is CRITICAL for clutch life.

🧠 CAN Decode Example (C)

void decode_can(uint32_t id, uint8_t *d, TCU *t) {
    if (id == 0x0CFFF048)
        t->rpm = (d[2] << 8) | d[3];

    if (id == 0x18FF0123)
        t->throttle = d[1];

    if (id == 0x18FF0201)
        t->engine_torque = (d[2] << 8) | d[3];
}

3️⃣ DRAG / RACE LOGIC (BOOST & TORQUE BASED)

🟥 Race Shift Strategy

Shift on RPM + torque drop
Lock converter before shift
No skip shifts under load
Full pressure

bool race_shift_allowed(TCU *t) {
    if (t->rpm > RPM_REDLINE_RACE)
        return true;

    if (t->engine_torque < t->last_torque - 120)
        return true;

    return false;
}

🔥 Launch Logic

2nd gear launch option
Locked converter above 20 mph
Max pressure immediately

4️⃣ TOW-GRADE THERMAL MODEL (THIS SAVES TRANSMISSIONS)

🌡️ Thermal Load Model

void thermal_model(TCU *t) {
    int load = t->engine_torque / 10;
    t->trans_temp += load / 50;

    if (t->mode == MODE_TOW && t->gear <= GEAR_3)
        t->trans_temp += 2;

    if (t->vehicle_speed > 40)
        t->trans_temp -= 1;
}

🚨 Protection Levels

Temp	Action
110°C	Increase pressure
120°C	Lock out race mode
130°C	Limp mode
140°C	Unlock TCC + force 3rd

5️⃣ HTG / PCS FILE CONVERSION GUIDE

🟦 HTG GCU

Your shift tables → Shift Speed Map
Line pressure → Duty Cycle vs Torque
Lockup → Slip Target Table
Torque request → CAN TX frame

HTG expects:

Gear-based tables
No adaptive learning (you code it)

🟥 PCS TCM-2800

Convert MPH tables → RPM
Pressure = PWM %
Torque request = analog or CAN

PCS limitation:
❌ No clutch-by-clutch logic
✔ Works great for tow rigs

🔌 1️⃣ COMPLETE WIRE PINOUTS (ZF 8AP → Standalone TCU)

This is generic ZF 8HP/8AP valve body logic, not VIN-locked OEM stuff.

🧠 TCU POWER & I/O

Function	Pin	Notes
Battery +12V	PWR1	Fused 15A
Ignition +12V	IGN	Keyed
Ground	GND1/GND2	Chassis + sensor ground
CAN H	CANH	500 kbps
CAN L	CANL	500 kbps
Mode Switch	DI1	Tow / Race
Brake Input	DI2	For downshift inhibit
Launch Arm	DI3	Drag only

⚙️ VALVE BODY SOLENOIDS

Solenoid	Function	Output
S1	Clutch A	PWM1
S2	Clutch B	PWM2
S3	Clutch C	PWM3
S4	Clutch D	PWM4
S5	Clutch E	PWM5
SL	Line Pressure	PWM6
ST	TCC Apply	PWM7

Use high-side drivers rated 2–3A continuous.

🌡️ SENSORS

Sensor	Type
Trans Temp	NTC
Output Speed	Hall
Input Speed	Hall (optional)
Line Pressure	0–300 psi

🧠 2️⃣ ESP32 / STM32 FIRMWARE DESIGN

✅ Recommended MCU

STM32F407 (preferred for motorsport)
ESP32 acceptable for testing / UI-heavy builds

🧩 Firmware Architecture

main()
 ├── CAN_RX_Task
 ├── Sensor_Task
 ├── Shift_Task
 ├── Pressure_Task
 ├── TCC_Task
 ├── Thermal_Task
 ├── Safety_Task
 └── UI_Task

🔁 Task Timing (REALISTIC)

Task	Rate
CAN RX	1 ms
Shift Logic	5 ms
Line Pressure	2 ms
TCC Control	5 ms
Thermal Model	50 ms
UI Update	100 ms

🧠 Core Firmware Loop (Simplified)

while(1) {
  read_can();
  read_sensors();
  update_thermal();
  calc_shift();
  calc_pressure();
  calc_tcc();
  safety_checks();
  output_solenoids();
}

📱 3️⃣ TOUCHSCREEN UI (RACE + TOW FRIENDLY)

🎛️ Display Pages

Main Screen

Gear
Mode (Tow / Race)
Trans Temp
Line Pressure
Lockup Status

Tune Screen

Shift RPM
Lockup MPH
Pressure Bias
Launch Mode

Diagnostics

Solenoid current
Slip RPM
Torque request %
Limp flags

📡 UI ↔ TCU Communication

UART or CAN
JSON or binary packets

Example:

SET MODE:RACE
SET SHIFT_RPM:3600
SET LOCKUP:ON

🧨 4️⃣ DYNO-SAFE TORQUE MODELS (CRITICAL)

🎯 Why This Matters

Protects clutches
Makes dyno tuning repeatable
Prevents flare or bind

🧮 Torque Estimation Model

estimated_torque =
  (rpm * throttle * boost) / 5252;

Then apply gear torque multiplication:

Gear	Multiplier
1	4.70
2	3.13
3	2.10
4	1.67
5	1.29
6	1.00
7	0.84
8	0.67

🧠 Torque → Pressure Map

Torque	Pressure
<400	50%
600	65%
800	75%
1000	85%
1200+	100%

This prevents clutch shock on the dyno.

🔄 5️⃣ TORQUE CONVERTER SLIP TUNING

(Drag + Sled Specific)

🟥 DRAG MODE

Lock early
Minimal slip
Hard coupling

if (gear >= 2 && throttle > 80)
  lockup = FULL;

Slip target:

50–100 RPM

🟦 SLED PULL MODE

Controlled slip
Prevents bog
Keeps turbo lit

if (gear <= 3)
  lockup = SLIP_200RPM;

Slip targets:

Launch: 300–400 RPM
Pull: 150–250 RPM

🔥 Adaptive Slip Logic

slip_error = target_slip - actual_slip;
tcc_pwm += slip_error * gain;

🧱 SAFETY LIMITS (NON-NEGOTIABLE)

Condition	Action
Temp > 120°C	Force Tow Mode
Slip > 500 RPM	Unlock TCC
RPM Spike	Abort shift
CAN Loss	Fixed 3rd gear

🔌 1️⃣ FULL WIRING DIAGRAM (ZF 8AP → Standalone TCU)

🧠 SYSTEM OVERVIEW (TEXT DIAGRAM)

          Cummins ECM
              │
        CAN H / CAN L
              │
        ┌─────────────┐
        │  STM32 TCU  │
        │  (F407)     │
        ├─────────────┤
 CAN ───┤ CAN1         │
 UART ──┤ UI / Debug   │
 ADC ───┤ Temp / Press │
 PWM ───┤ Solenoids    │
        └─────────────┘
              │
     ┌───────────────────┐
     │ ZF 8AP Valve Body │
     │ S1–S5, SL, ST     │
     └───────────────────┘

🔋 POWER & COMMUNICATION PINOUT

STM32F407 (LQFP100 example)

Function	STM32 Pin	Notes
+12V	External	Buck to 5V
+5V	VDD	MCU
GND	VSS	Star ground
CAN RX	PB8	CAN1
CAN TX	PB9	CAN1
UART TX	PA9	UI
UART RX	PA10	UI

⚙️ SOLENOID OUTPUT PINOUT

Solenoid	Function	STM32 Pin
S1	Clutch A	TIM1_CH1 (PA8)
S2	Clutch B	TIM1_CH2 (PA9)
S3	Clutch C	TIM1_CH3 (PA10)
S4	Clutch D	TIM1_CH4 (PA11)
S5	Clutch E	TIM3_CH1 (PA6)
SL	Line Pressure	TIM3_CH2 (PA7)
ST	TCC	TIM4_CH1 (PB6)

All PWM outputs go to high-side drivers (VNQ5E160 / BTS500xx).

🌡️ SENSOR INPUTS

Sensor	STM32 Pin	Type
Trans Temp	PA0	ADC
Line Pressure	PA1	ADC
Input Speed	PB4	Timer input
Output Speed	PB5	Timer input

🧩 2️⃣ PCB SCHEMATIC (FUNCTIONAL BLOCKS)

🟦 POWER SUPPLY

12V ── Fuse ── TVS ── Buck (LM2596) ── 5V
                         │
                       LDO
                         │
                        3.3V (STM32)

🟥 CAN INTERFACE

STM32 CAN_TX ─┐
              ├─ MCP2562 ── CAN_H
STM32 CAN_RX ─┘              CAN_L

🟨 SOLENOID DRIVERS

STM32 PWM ── Gate ── High-Side Driver ── Solenoid ── GND

Flyback handled internally by driver IC.

🟩 SENSOR CONDITIONING

NTC: voltage divider → ADC
Pressure: 0–5V → resistor divider → ADC
Speed: hall → pull-up → timer capture

🧠 3️⃣ REAL STM32 HAL CODE (WORKING BASE)

⏱️ PWM INIT (TIM1 example)

TIM_HandleTypeDef htim1;

void MX_TIM1_Init(void)
{
  TIM_OC_InitTypeDef sConfigOC = {0};

  htim1.Instance = TIM1;
  htim1.Init.Prescaler = 84-1;
  htim1.Init.CounterMode = TIM_COUNTERMODE_UP;
  htim1.Init.Period = 1000-1;
  HAL_TIM_PWM_Init(&htim1);

  sConfigOC.OCMode = TIM_OCMODE_PWM1;
  sConfigOC.Pulse = 0;
  sConfigOC.OCPolarity = TIM_OCPOLARITY_HIGH;

  HAL_TIM_PWM_ConfigChannel(&htim1, &sConfigOC, TIM_CHANNEL_1);
  HAL_TIM_PWM_Start(&htim1, TIM_CHANNEL_1);
}

📡 CAN RX (Torque, RPM)

void HAL_CAN_RxFifo0MsgPendingCallback(CAN_HandleTypeDef *hcan)
{
  CAN_RxHeaderTypeDef rx;
  uint8_t data[8];
  HAL_CAN_GetRxMessage(hcan, CAN_RX_FIFO0, &rx, data);

  if (rx.StdId == 0x0CFFF048)
    rpm = (data[2] << 8) | data[3];

  if (rx.StdId == 0x18FF0201)
    torque = (data[2] << 8) | data[3];
}

⚙️ SOLENOID OUTPUT

void set_pwm(TIM_HandleTypeDef *htim, uint32_t ch, uint16_t duty)
{
  __HAL_TIM_SET_COMPARE(htim, ch, duty);
}

🔄 MAIN LOOP (REALISTIC)

while (1)
{
  read_sensors();
  update_thermal();
  calc_torque();
  shift_logic();
  pressure_control();
  tcc_control();
  safety();
}

📊 SHIFT TABLE (HTG FORMAT)

Tow

Gear 1→2: 14 mph
2→3: 24 mph
3→4: 34 mph
4→5: 44 mph
5→6: 54 mph
6→7: 64 mph
7→8: 74 mph

Race

1→2: 28 mph
2→3: 48 mph
3→4: 68 mph
4→5: 88 mph
5→6: 108 mph
6→7: 128 mph
7→8: 148 mph

🔧 LINE PRESSURE TABLE (HTG %)

Torque	Pressure
400	55%
600	65%
800	75%
1000	85%
1200	100%

🔄 TCC TABLE (HTG)

Gear	Lock
1	OFF
2	RACE ONLY
3+	ON
